ASME forged stainless steel round tube sheet flange

Hebei Haihao Group specialized in flange, pipe fittings and steel pipe. Below is the details of tube sheet flange:

Features of tube sheet flange:

(1) Forged Flange

(2) Size: 10″-250″

(3) Class: PN0.6Mpa, PN1.0Mpa, PN2.5Mpa, PN4.0Mpa, etc

(4) Stainless steel flange, carbon steel flange and alloy steel flange
Stainless steel flange: A182 F304/304L, F316/316L, 317, 321, 310s, 316ti, 316H.317H.317L. 904L, 321H,347H, 310H, UNS31803, UNS32750, UNS32760 , nickel alloy inconel 600, inconel 625, inconel 601, inconel 690, inconel 625,inconel 718,incoloy 800, incoloy 825, incoloy 800h, C-276,monel 400, alloy 20 etc.
Carbon steel flange: C22.8, A105, SA350 LF2, P280GH, P250GH, Q235B, Q345E
Alloy steel flange: F11, F22, F51, F53, 16Mo3, TStE355 etc

(5) Standard: ASME, ANSI, API, DIN, BS, EN, JIS, JPI

(6) Certificates: ABS, ISO, PED, BV

(7) Delivery: 15-25days

(8) Packing: Wooden box, sea-worthy plywood pallets with polyethylene film or steel cases or as customers’ request.

4.2 Diameters Tube Sheet In Haihao Group

We manufacture all kinds of flanges, such as forged SO flange,BL flanges,WN flange,PL,etc.

GB GB/T4700-4707 (Flanges for Pressure Vessels),GB/T9112-9124 (Pipe Flange)
JB/T4726-4728 (Steel Forgings for Pressure Vessels)
JB/T6396-6398 (Large-Scale Steel Forgings Made of Alloy Steel,Carbon steel,Stainless Steel,Acid-Proof Steel and heat resistant steel)
HG20592-20635 (Pipe Flange)
SH3406 (Steel Pipe Flange)
ASTM
ASME
ASME B16.5 (Pipe Flange)
A403/A403M (Wrought Austenitic Stainless Steel Piping Fittings)
A182/A182M (Alloy Steel Forgings for high-Temperature)
A105/A105M (Carbon Steel Forgings for Piping)
A234/A234M (Piping Fittings of Carbon Steel and Alloy Steel for Moderate and High Temperature)
A350/A350M (Carbon Steel and Low-Alloy Steel Forgings, Requiring Notch Toughness Testing)
JIS G3214 (Stainless Steel Forgings for Pressure Vessel)
JIS B2220 (Steel Pipe Flange)
DIN DIN2512-86030 (Steel Pipe Flange)
EN EN10222-1~5(Steel Forgings for Pressure Purposes)

If you have any inquiry of tube sheet flange, please do not hesitate to contact me.Email:sales@haihaogroup.com
