Haihao Group Supplies Klingersil C-4430 Flange Gaskets to Russian Client
Haihao Group has recently completed the shipment of Klingersil C-4430 non-asbestos flange gaskets to a valued client in Russia.
These precision-engineered gaskets are designed to ensure reliable sealing performance in critical industrial pipeline systems, where resistance to pressure, temperature, and chemical exposure is essential.
Detailed Product Specifications
The supplied flange gasket products were produced strictly according to the client’s drawings and project specifications.
Each gasket was cut with high dimensional accuracy to match ASME and custom flange standards, providing consistent sealing under fluctuating operating conditions.
Klingersil C-4430 flange gaskets ready for shipment to Russia
Product details include:
| Description | Size & Dimensions | Material | Standard |
|---|---|---|---|
| Flange Gasket | 28″ CL150, OD 925 mm, ID 715 mm, thickness 3 mm, 28×Φ35×864 | Klingersil C-4430 | Drawing |
| Flange Gasket | OD 813 mm, ID 715 mm, thickness 3 mm, 40×Φ19×774.7 | Klingersil C-4430 | Drawing |
| Flange Gasket | OD 933 mm, ID 819 mm, thickness 3 mm, 24×Φ14×893 | Klingersil C-4430 | Drawing |
| Flange Gasket | OD 1060 mm, ID 817 mm, thickness 3 mm, 28×Φ43×978 | Klingersil C-4430 | Drawing |
All gaskets were carefully inspected before shipment to ensure compliance with tight tolerance, thickness uniformity, and flatness requirements.
Why Klingersil C-4430 Gaskets?
Klingersil C-4430 is a premium-grade fiber-reinforced gasket material based on aramid fibers and nitrile rubber (NBR).
It offers exceptional chemical resistance, mechanical strength, and temperature stability, making it ideal for oil and gas, chemical, power generation, and marine applications.
Key advantages:
- Excellent resistance to oils, steam, and aggressive chemicals
- Outstanding compressibility and recovery under load
- Reliable sealing at pressures up to 100 bar and temperatures up to 200°C
- Non-asbestos, environmentally friendly composition
By choosing Klingersil C-4430 flange gaskets, Haihao ensures safe and leak-free performance even in harsh industrial environments.
Precision Manufacturing and Quality Assurance
Haihao Group’s gasket production process combines CNC cutting technology with stringent quality control to meet the highest international standards.
Each gasket undergoes:
- Dimensional and surface inspection
- Material verification and batch traceability
- Compression and sealing performance tests
The final products are securely packed to prevent deformation during transit, ensuring our Russian client receives gaskets ready for immediate installation.
Serving Global Energy and Pipeline Projects
Haihao Group continues to support major oil, gas, and petrochemical projects worldwide with custom-engineered sealing solutions.
